How to Install CSF Firewall on Linux and cPanel Servers

How to install CSF ConfigServer Security Firewall on Linux and cPanel servers step by step
IAMEM HOSTING HOST
 February 3, 2016 No Comments

ConfigServer Security & Firewall (CSF) is one of the most widely used stateful packet inspection firewalls for Linux servers. It integrates natively with cPanel/WHM and provides a powerful web UI, brute-force detection via Login Failure Daemon (LFD), port-knocking, rate limiting, and much more. This guide covers the complete installation and initial configuration on both bare CentOS/RHEL servers and cPanel-managed servers.

Prerequisites

  • CentOS 6/7/8, RHEL, CloudLinux, or Ubuntu server
  • Root SSH access
  • wget, perl, and iptables installed
  • On cPanel servers: WHM access for the CSF plugin UI

Step 1: Download the CSF Package

Navigate to the /tmp directory and download the latest CSF tarball directly from the official ConfigServer source:

cd /tmp
wget https://download.configserver.com/csf.tgz

Step 2: Extract and Run the Installer

Extract the archive and run the installation script. The installer automatically detects whether cPanel is present and installs the WHM plugin accordingly:

tar -xzf csf.tgz
cd csf
sh install.sh

The installer will:

  • Install CSF and LFD (Login Failure Daemon)
  • Detect and configure cPanel/WHM integration if present
  • Install the CSF WHM plugin under WHM → Plugins → ConfigServer Security & Firewall
  • Place the main config file at /etc/csf/csf.conf

Step 3: Test the CSF Installation

Run the built-in test script to verify that all required kernel modules are available and working correctly:

perl /usr/local/csf/bin/csftest.pl

A successful installation produces the following output — all modules should show OK:

Testing ip_tables/iptable_filter...OK
Testing ipt_LOG...OK
Testing ipt_multiport/xt_multiport...OK
Testing ipt_REJECT...OK
Testing ipt_state/xt_state...OK
Testing ipt_limit/xt_limit...OK
Testing ipt_recent...OK
Testing xt_connlimit...OK
Testing ipt_owner/xt_owner...OK
Testing iptable_nat/ipt_REDIRECT...OK
Testing iptable_nat/ipt_DNAT...OK

RESULT: csf should function on this server

If any module shows FAILED, that kernel module is not loaded. On OpenVZ or some VPS platforms, certain modules may be unavailable — contact your hosting provider to have them enabled at the hypervisor level.

Step 4: Configure CSF

Before enabling CSF in production mode, review and update the main configuration file:

nano /etc/csf/csf.conf

Key settings to review:

  • TESTING = "1" — CSF starts in testing mode by default (auto-flushes rules every 5 minutes). Change to TESTING = "0" only after you have confirmed your SSH and management ports are open.
  • TCP_IN / TCP_OUT — Comma-separated list of allowed inbound/outbound TCP ports. Ensure port 22 (SSH) and any custom SSH port are listed before disabling testing mode.
  • LF_TRIGGER — Controls how many login failures before an IP is blocked. Default is 10; lower this to 5 for tighter security on public servers.

Step 5: Allow Your IP and Disable Testing Mode

Add your management IP to the whitelist so you cannot accidentally lock yourself out, then disable testing mode and restart:

# Add your IP to the permanent allow list
echo "YOUR.MANAGEMENT.IP.HERE" >> /etc/csf/csf.allow

# Disable testing mode in csf.conf
sed -i 's/TESTING = "1"/TESTING = "0"/' /etc/csf/csf.conf

# Restart CSF and LFD
csf -r
service lfd restart

Useful CSF Commands

CommandDescription
csf -rRestart CSF and reload all rules
csf -lList current iptables rules applied by CSF
csf -d [IP]Permanently block (deny) an IP address
csf -a [IP]Permanently allow an IP address
csf -df [IP]Remove an IP from the deny list
csf -g [IP]Check if an IP is currently blocked
csf -xDisable CSF (flush all rules)
csf -eRe-enable CSF
